KEL-DPU 24/16 – Grey

Documentation

Product Description

This robust cable entry plate is designed for secure and highly sealed cable routing in control cabinets, machinery, and industrial installations. Manufactured in Germany and made from a durable elastomer and polypropylene combination, it provides long-term reliability even in harsh environments.

With protection ratings up to IP68, this cable entry plate offers excellent resistance against dust, water, and environmental stress. The flexible sealing inserts accommodate multiple cable diameters, ensuring quick installation, strong cable retention, and tidy cable management. With both screw mounting and snap-in installation options, it allows fast and versatile assembly.

Ideal for applications where high sealing performance, durability, and organized cable routing are essential.

Specifications

• HS Code: 85472000

• Country of Origin: Germany

• Material: Elastomer / Polypropylene

• Color: Grey

• Height: 58 mm

• Installation Cut-out Size: 36 × 112 mm

• Width: 147 mm

• Depth: 14 mm

• Clamping Range:

  • 8 × 3.2–5.5 mm

  • 6 × 5–8.5 mm

  • 2 × 9.5–14.5 mm

• Temperature Range: -40°C to +100°C

• Protection Rating: IP66 / IP68

• Mounting: Screw mounting, Snap-in

• Net Weight: 0.112 kg
